Helical
Rotor (Progressive Cavity) Pumps |
 |
|
|
| |
The CEMO progressive cavity,
positive-displacement pump is one of the most versatile
designs on the market. Applications include
Agricultural, Mining, Manufacturing, Waste-water, Water
Utilities, Chemical, Petroleum and general industry
fluid transfer. Our industrial range includes the SP
(Small Pump), WDS (Widethroat), CB (Close-Coupled), O
(Industrial), and HP (High Pressure) Ranges. Our
extensive range of CEMO Pumps deliver flow rates up to
200m3/hr
and pressures of up to
720m.
A full service backup capability and comprehensive range
of spares support all products. |
|
| |
|
|
| |
The Pumps in this range are SP1, SP2, SP3, SP3L, SP4 and
SPGB |
|
| |
|
|
| |
|
|
| |
|
|
| |
|
The WDS Widethroat Pump Range |
 |
|
|
|
| |
|
|
| |
The CEMO
WDS- range
medium flow, high head positive displacement pumps are
used for |
|
| |
medium to heavy industrial use. They comprise of a
steel rotor withing a rubber stator including |
|
| |
a large in product hopper let and auger assembly. Pumps
may be close coupled or belt driven |
|
| |
on depending the application. |
|
| |
Applications include domestic and industrial waste
water transfer, molasses, vegetable waste |
|
| |
and animal feed and grain transfer. Butter,
pastes, food pulps, industrial pulps, heavy resins, |
|
| |
sludge and most viscous non-flowing product
transfer and other process plant applications. |
|
| |
Advantages include a wide range of materials of
construction available to suit food, pharma- |
|
| |
ceutical and chemical
pumping applications. |
|
| |
Other advantages include variable speed drives to
vary required flow rates. |
|
| |
|
|
| |
The Following Pumps are in the WDS Range |
|
|
|
|
| |
| |
WDS220 |
WDS310 |
WDS320 |
WDS410 |
|
|
| |
WDS420 |
WDS610 |
WDS620 |
WDS640 |
|
|
| |
WDS710 |
WDS720 |
WDS730 |
WDS750 |
|
|
| |
WDS810 |
WDS820 |
|
|
|
|
| |
WDS915 |
WDS9155 |
|
|
|
|
| |
WDS910 |
WDS920 |
|
|
|
|
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
The "O"
Industrial Pump Range |
 |
|
|
|
| |
The "O"
Range (Industrial Range) low to medium flow, high head
positive displacement pumps |
|
| |
for use in the medium to heavy industrial use
comprising of a steel rotor within a rubber stator. |
|
| |
Pumps may be close coupled or belt driven
depending on application.Applications include |
|
| |
domestic and industrial waste water transfer, mining water of any
composition, gland service |
|
| |
water pump for slurry pump glands. Industries
serviced includes the beverage, brewery |
|
| |
industrial, chemical, pharmaceutical and petroleum industries. |
|
| |
These pumps are also used in
for agricultural, farming and irrigation pumping
requirements. |
|
| |
Some are used for high pressure
cleaning for the railroad and trucking industries. They
also |
|
| |
cater bilge pumps for marine and barge applications
and process plant applications. Foam |
|
| |
and lightweight cement grouting and pumping for both domestic, industrial
& mining applications |
|
| |
the are also outfitted. Advantages include a wide
range of materials of construction available to |
|
| |
suit food, pharmaceutical and chemical
pumping applications. |
|
| |
Other advantages include variable
speed drives to vary required flow rates. |
|
| |
| |
The Following Pumps are in the "O"
Range |
|
|
| |
| |
C220 |
|
|
|
|
|
C310 |
C320 |
|
|
|
| |
C410 |
C420 |
|
|
|
| |
C610 |
C620 |
C640 |
|
|
|
C710 |
C720 |
C730 |
C750 |
|
| |
C810 |
C820 |
|
|
|
| |
C910 |
C915 |
C920 |
C9155 |
|
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
HP High Pressure Pump Range |
 |
|
| |
|
|
|
|
| |
The HP-Range is a
medium to high flow, high head positive displacement
pump for medium to |
|
| |
heavy industrial and mining use. The pumps comprise of a
steel rotor within a rubber stator. |
|
| |
Pumps may be close coupled, gearbox or belt driven
depending on application. Applications |
|
| |
include clean water transfer,
gland service on slurry pumps, agricultural use,
irrigation, high |
|
| |
pressure water jetting for the cleaning and descaling of
agricultural implements, earth moving |
|
| |
equipment and
railroad rolling stock and locomotive undercarriage
cleaning, process plant |
|
| |
applications and more.
Advantages include a wide range of materials of
construction available |
|
| |
to suit food, pharmaceutical and
chemical pumping applications. |
|
| |
Other advantages
include variable speed drives, to vary required flow
rates. |
|
| |
|
|
| |
| The
Following Pumps are in
the HP-Range |
HP30S |
HP30 |
| |
HP50 |
HP50H |
| |
HP115 |
HP115H |
| |
HP250 |
|
|
|
| |
|
|
| |
|
|
Clear Water Multi-Stage Pumps |
 |
|
|
| |
|
|
| |
|
CPH 484 |
CPH 505 - CPH 580 |
RTB 530 - 580 |
 |
|
 |
|
|
| |
|
|
| |
The CEMO
highly efficient
multistage pumps are manufactured with the highest grade
of certified materials and ultra-precise machining. The
Clearwater range includes our CPH 480, CPH 505, CPH 530,
CPH 540 and our CPH 580 pumps. These high flow (415
m3/hr 888 m3/hr) pumps can be used with a range of
pressures provided by the number of stages in series.
(Up to 120 Bar.)
Materials of construction are
sand and die cast PB1 Phosphor bronze impellers,
diffusers, shaft sleeves, neck rings, neck bushes,
balance and counter disc components. All stage casings,
suction and delivery covers are cast from A-2 Steel or
Gr17 Cast Iron or SG42 nodular iron as per customer's
requirements. Anti-abrasive coatings such as HVOF
tungsten carbide, ceramic coatings and chrome plated
coatings are used on wear susceptible wetted components
or rotating element assemblies.
All rotating element
individual components and assemblies are balanced to ISO
19401 prior to assembly. All pump shafts are
non-destructively tested and heat-treated to relieve
residual stresses. Pump bearing types include either
white metal shell types or branded roller bearing types
dependent on pump type and model.
We also refurbish various
other OEM multistage type pumps with our extremely high
quality machined components which are interchangeable
with these pumps, as well as innovative hydraulic
improvements for enhanced pump performance and
efficiencies. Independent test results showing
improvements are available on request.
Our in house foundry and all
on site machining undertaken on our premises ensures
speedy delivery of a quality engineered product. All
processes follow our accredited ISO 9001:2008 quality
standard. Independent pump testing is carried out at the
South African Bureau of Standards (SABS) and all pumps
are tested to ISO 9906:2012 Grade 1 standards unless
otherwise specified by client.
On site commissioning and
pump condition monitoring are carried out b y our field
service engineers and technicians who are available 24
hours/day, 7 days a week for commissioning and breakdown
services. On-site pump repairs to wear faces, balance
valve assemblies are also carried out by the same team
of pump experts. Pump condition monitoring is also a
service offered by our pump field service team on either
a monthly or fixed periodic basis. Monitoring includes
pump flow readings, pressure readings, energy
consumption and overall efficiency. |
|
| |
|
|
| |
|
|
| |
|
|
| |
|
CEMO Multistage Centrifugal Pumps - CPH Range |
| |
|
|
|
|
The Following
Pumps are in the
Clear Water
Multi-Stage Pumps : |
| |
|
CPH 505 |
CPH 530 |
|
|
CPH 540 |
CPH 580 |
|
| |
|
The Robday Mining Consultant can
assist you in selecting the correct pump
size |
|
Please Request a Curve Sheet |
|
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
CEMO Multistage Centrifugal Pumps - RTB Range |
|
| |
|
|
|
The Following
Pumps are in the
Clear Water
Multi-Stage Pumps : |
|
|
|
|
|
RTB 530 |
RTB 540 |
RTB
580 |
|
|
|
The Robday Mining
Consultant can assist you in
selecting the correct pump size |
|
Please Request a Curve
Sheet |
|
|
|
|
|
|
| |
|
| |
|
CEMO Multistage Centrifugal Pump -
CPH 484 Range |
|
|
| |
|
CPH 484 |
|
|
| |
|
|
|
The Robday
Mining Consultant can
assist you in selecting
the correct pump size
|
|
|
|
Please Request a
Curve Sheet |
|
|
| |
|
|
|
| |
|
|
| |
High Pressure Plunger
Pump Range
|
| |
|
Crown
Plunger Pumps |
|
Crown
Plunger Pump
Range |
 |
|
|
Crown
320 Triplex
Plunger Pump |
|
Crown
701 Triplex
Plunger Pump |
|
Crown
701 Quintuplex
Plunger Pump |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Crown
Triplex Mud
Pumps |
Crown
Triplex Mud
Pumps Range |
 |
|
Crown
120 Triplex Mud
Pump |
|
Crown
737 Triplex Mud
Pump |
| |
| |
| |
|
|
Crown 120 and Crown 737
are an underground
industrial standard
known for their mud
pumping abilities with
SG s of up to 1.2. The
high flow (up to
44m3/hr) and high
pressures (up to 225
Bar) achievable on these
pumps are what make them
perfect for underground
mine mud transfer as
well as sewage plant
sludge movement. These
pumps are also
extensively used in
steel mill plate
descaling, mud drilling
and for pumping light
tar s and resins within
the petro-chemical
industry. Materials of
construction include
fabricated steel casings
with bronze crosshead
wear liners, nodular
iron eccentric and
connecting rods
transferring the fluid
via steel, thermally
coated plungers through
forged steel fluid ends.
Eccentric drive is via
heat treated jackshaft
pinions on eccentric
ring gears. The pumps
recommended slow
eccentric speed (120
rpm) ensures pump
reliability and wear
component longevity. |
|
|
|
|
|
| |
|
|
| |
Helical Rotor Borehole Pumps
|
 |
 |
|
|
| |
| Our helical rotor borehole pumps are the
staple in rural and agricultural areas. These
easily assembled and maintained pumps can manage
a large range of duties up to 84m3/hr and up to
300m head. Our drivehead design offers light and
heavy duty options and allows for electric
motor, diesel or petrol engine and hand driven
drives. |
|
|
|
|
| |
|
|
| |
The Following Pumps are in
the Helical Rotor Borehole Pump Range : |
|
| |
| |
P10 |
P30 |
P75 |
P150 |
P300 |
P400 |
| |
P10H |
P30H |
P75H |
P150S |
P300A |
P400S |
| |
P10S |
P30S |
P100 |
P200 |
P300S |
|
| |
P15 |
P50 |
P100S |
P200B |
P315 |
|
| |
P15H |
P50H |
P115 |
P200H |
P350 |
|
|
P15S |
P50HH |
P115H |
P200S |
P350A |
|
| |
|
|
P115S |
|
P350S |
|
|
|
|
